Features
1. The microsuction side is easy to stick and remove repeatedly.
2. If the microsuction side becomes dirty, wipe the surface with a wet tissue and it becomes reusable as before.

Description

~REGABOND-S,
it's the amazing reusable microsuction tape! ~

REGABOND-S is the amazing reusable micro suction tape which can stick and remove repeatedly without glue. The features and applications are as following.

〈Why can it stick and remove ?〉

(Magnified Photo)

The backing of REGABOND-S is acrylic foam. One side is ordinary adhesive though, the other side has no glue. The non-glue side has innumerable sucker-like microscopic nano suctions. The micro suction cups creating vacuum can stick and remove on almost any smooth, flat, non porous surfaces similar to ordinary suction cups. Though the suction force weakens when the surface becomes dirty, you can clean it with a wet tissue or a scotch tape, and it will be reusable and work again.

◆For temporary signs

You can fix temporary signs to the wall without bond, adhesive tapes, screws, or nails. Stick the adhesive side to the sign, and fix it to the wall with the micro suction side. You can stick and remove the sign without leaving any sticky residue on the wall.

◆For tablet and smartphone accessories

Affixing tablets or smartphones to folio cases are popular applications. Recently, it is used for a ring holder attaching the back side of a smartphone. If it is used as a rubber foot of a tablet, a smartphone, and a smartwatch docking station, and a wireless battery charger, a smart speaker, you can fix it tightly mounting on a desk and which prevents it from falling down. For a stand or a docking station, REGABOND-S is used for attaching a smartphone or a tablet to the stand and fixing the stand on a desk. You can stick and remove it easily and repeatedly.

◆As smartphone components

REGABOND-S is used as LCD gaskets in smartphones. It shuts out the dust perfectly, and is removable if repairs are necessary. When you drop the phone, the foam absorbs the shock and protects the acrylic or glass window from breaking. It is also effective for fixing of the battery not to move in the housing. As the ring cushion for the microphone and speaker, it prevents the sound leakage and improves the quality of the sound.

◆Instead of magnet

Different from magnets, it can stick to almost any flat surface. You can use it around computers with no bad influence like magnets.

◆With your idea

You can use REGABOND-S as various components for industrial products, stationeries and household products (bookends, pencil stands, name plates, wall pockets, dry-erases / whiteboards, carpets, e.g.). Please use it freely with your idea!

Construction

Standard

Color
Thickness/mm
Foam Thickness/mm
Protection Film
Thickness/mm
Paper Liner
Thickness/mm
Black, White
0.6
0.5
0.06
0.13

Object

Usable
Unusable
Flat surface material
Glass, Metal,Marble, Plastic etc.
Rough surface
Wet Area

Applications

1
Stand, Docking station (Attaching a tablet or a smartphone / A rubber foot )
2
Smartphone and tablet accessories ( Fixing to a folio case, a ring holder)
3
Gaskets for internal components of smartphone (LCD, Battery, Speaker, Microphone e.g.)
4
Stationery fixation (Bookends, Pencil stand, name plate, dry-erase / whiteboard e.g.)

Storing

Please store the product in a tightly wound fashion. It will become wrinkled if it loosens.

FAQ about REGABOND-S

「Suitable Size」

The suitable size of REGABOND-S depends on the fixing power and removability balance. Just for fixing, larger size is stronger though, easy removability is the most important feature of this product. So, the size has to be largest within removable range. The suction force depends on the material and smoothness condition of the adherend, direction of theforce, and the other various factors. Please test with samples in various sizes considering good balance under your practical condition of use.

「How to apply」

If you peel off the paper liner completely and apply REGABOND-S horizontally to the adherend by hand, the air will enter between the adhesive and the adherend easily. The best way to apply REGABOND-S is: 1. Peel the paper liner a little from the edge. 2. Stick REGABOND-S from the edge by inches with a hand roller, a cloth, or a finger pad extruding aircarefully, peeling the paper liner little by little.

「Cleaning Method」

If the microsuction side becomes dirty and the suction strength weaken, you can clean the material with a moist cloth or rinse under a little water. It will work again after the water dry out. Please take care not to damage the adhesive side with too much water. To clean it with Scotch tape or a masking tape is an effective way too. If your application needs to stick-and-tear behavior frequently, we recommend not using white color because it shows up dirt. In that case we think black color might be better aesthetically.

「If the suction is difficult to remove」

The suction strength may also be very strong depending on the material of the surface to which it is attached and the conditions of the environment in which it is used. Also, if REGABOND-S has been used in high temperature and it return to normal temperature, the suction strength will be stronger because the air in the suctions is shrunk. If the peeling force feels stronger than usual, to prevent delamination, please peel off REGABOND-S slowly and carefully little by little from the edge. Still, it seems to be difficult to remove, please soak the sticking surface of the foam with a little water. That makes the removal easy and the suction will revive as the water dry out.

「Protection Film」

REGABOND-S has strong suction strength. Particularly in summer time, the foam will be softer, so the suction strength will be stronger and the protection film may be difficult to remove. In that case, please stick a one-sided tape (like a cellophane tape, or a packing tape) at the corner of the protection film and pull the tape swiftly in a vertical direction.

「Carrier Sheet」

When you die-cut REGABOND-S and replace the original protection film with a raw film as the carrier sheet for the suction side, there are cases the suction strength will be extremely strong and hard to remove due to the extremely high surface smoothness of the unused virgin film. To prevent that, we recommend to use a silicone coated paper or film (an ordinary release paper or film for adhesive tapes) instead.
